Full Convection Reflow Soldering Systems
R-Series reflow soldering systems engineered for maximum efficiency, high throughput, and stable soldering quality across six heating zone configurations from 2.1 m to 4.6 m.
Product Overview
The SMT Wertheim R-Series Full Convection Reflow Soldering Systems are designed to deliver process-optimized soldering profiles with maximum energy efficiency and high product throughput. An innovative heating zone concept with continuously adjustable fan units provides stable soldering quality while keeping energy and media consumption at the lowest level in the industry, resulting in an improved CO₂ balance.
The R-Series features gas-tight, maintenance-free fan units built for the life of the system, combined with an optimized process gas cleaning concept that significantly reduces maintenance effort. All maintenance tasks can be performed tool-free, with extended intervals that minimize production downtime. The smooth cooling plates prevent clogging and never require replacement, while the modular cooling equipment is easy to clean and service.
Advanced lambda sensor technology enables exact nitrogen management with continuous real-time residual oxygen measurement, and probe replacement can be completed in under 10 minutes. Individual fan speed adjustment per zone, combined with separate fan control from motors, ensures long-term durability and precise process control. Integrated monitoring software detects even the smallest process gas deviations, ensuring consistent quality across every board.
Key Features
- Innovative heating zone concept with continuously adjustable fan units for process-optimized soldering profiles
- Lowest energy and media consumption in its class with improved CO₂ balance
- Gas-tight, maintenance-free fan units designed for the life of the system
- Tool-free maintenance with extended maintenance intervals
- Optimized process gas cleaning reducing maintenance effort
- Smooth cooling plates that prevent clogging — no replacement necessary
- Easy-to-clean modular cooling equipment
- Lambda sensor technology for exact nitrogen management
- Continuous real-time residual oxygen measurement
- Probe replacement in under 10 minutes
- Individual fan speed adjustment per zone for precise thermal profiles
- Separate fan control from motors for extended component life
- Monitoring software detecting minimal process gas deviations
R-Series Model Overview
| Model | Heating Zone Length |
|---|---|
| R210 | 2.1 m |
| R250 | 2.5 m |
| R320 | 3.2 m |
| R360 | 3.6 m |
| R410 | 4.1 m |
| R460 | 4.6 m |
